LUMii SWITCH BLADE

Full control. Maximum flexibility.
The LUMii SWITCH BLADE is the compact all-in-one LED solution for all indoor growers who like it simple and efficient.
Switch between VEG & BLOOM at the flick of a switch - or between 100W and 150W output at the touch of a button. Plug & play, controllable, linkable - simply connect and get started.

Key features:

• Dual spectrum: VEG & BLOOM in one device
• 2-stage output: 100W or 150W - as required
• Daisy chain ready: power* & control in series possible
• Externally controllable: 0-10V via RJ port (compatible with XLED controllers)
• Ready for immediate use: plug & play
• Ultra light: only 1.35 kg
• Highly efficient & durable: up to 30. 000 hours service life

(* up to four units from a single mains socket – link leads required separately)

Technical data:

Modus	VEG	BLOOM
Power	100W / 150W	100W / 150W
Output	2.5 µmol/J	2.6 µmol/J
PPF	250 / 375 µmol/s	260 / 390 µmol/s

Further specifications:

• Input voltage: 200-264V AC / 50-60 Hz
• Current consumption: max. 0.75 A
• Beam angle: 120°
• Protection class: IP22
• Dimming: 0-10V external
• Dimensions (L×W×H): 350 × 350 × 55 mm
• Weight: 1.35 kg
