RAM Mixed-Flow Inline Fan
Quantity:
In Stock
Sold out
Usually ready in 1 hour —
RAM Mixed-Flow Inline Fan – Powerful Dual-Speed Hydroponic Extractor Fan
Experience powerful, reliable ventilation with the RAM Mixed-Flow Inline Fan, a high-performance AC extractor fan designed to deliver excellent airflow, quiet operation and efficient extraction for hydroponic grow rooms, grow tents, greenhouses and indoor growing environments.
Manufactured by RAM (Rapid Air Movement), this professional inline extractor fan combines advanced mixed-flow technology with a powerful AC motor to provide effective ventilation, helping control excessive heat, humidity and stale air.
Designed for growers seeking dependable performance at an affordable price, the RAM Mixed-Flow Fan delivers strong extraction pressure and quieter operation than many basic axial extractor fans.
Advanced Mixed-Flow Technology
The RAM Mixed-Flow Inline Fan combines the airflow characteristics of axial and centrifugal fans, providing an excellent balance of high air movement, strong static pressure and reduced operational noise.
This makes it particularly suitable for hydroponic extraction systems incorporating carbon filters, flexible ducting and ventilation accessories, where maintaining effective airflow is essential.
Dual-Speed Ventilation Control
Unlike conventional single-speed extractor fans, the RAM Mixed-Flow Inline Fan features two selectable speed settings, allowing growers to adjust ventilation performance according to their requirements.
Choose the lower setting to reduce airflow and operating noise during cooler periods, or switch to the higher setting when additional extraction is required.
The fan also features a convenient Fast Clean release system, allowing the motor and impeller assembly to be accessed for easier cleaning and maintenance.
Its integrated mounting bracket and IEC connection make installation straightforward, providing a practical solution for new and existing ventilation systems.
Available Sizes & Maximum Airflow Rates
| Fan Size | Low Speed | High Speed |
|---|---|---|
| 100mm (4") | 165m³/h | 199m³/h |
| 125mm (5") | 248m³/h | 284m³/h |
| 150mm (6") | 398m³/h | 517m³/h |
| 200mm (8") | 690m³/h | 840m³/h |
Airflow figures are maximum free-air ratings. Actual extraction performance will depend on connected carbon filters, ducting length, bends and installation resistance.
Key Features & Benefits
-
Powerful Mixed-Flow Technology – Combines excellent airflow with strong extraction pressure.
-
Dual-Speed AC Motor – Choose between two fan speeds to suit your ventilation requirements.
-
Maximum Airflow Up to 840m³/h – Suitable for compact grow tents and larger indoor growing spaces.
-
Quiet Operation – Aerodynamic mixed-flow design helps minimise unnecessary fan noise.
-
High Static Pressure Performance – Suitable for compatible carbon filters and ducting systems.
-
Energy-Efficient Ventilation – Adjustable airflow helps reduce unnecessary electricity consumption.
-
Fast Clean Release System – Convenient access for cleaning and routine maintenance.
-
Integrated Mounting Bracket – Simplifies installation in grow rooms and ventilation systems.
-
IEC Power Connection – Straightforward connection using a compatible mains lead.
-
IP44 Protection Rating – Designed to resist splashing water and ingress of solid objects.
-
Effective Temperature Management – Helps extract excess heat from growing environments.
-
Humidity Management – Supports moisture removal and fresh air circulation.
-
Carbon Filter Compatible – Can be paired with an appropriately sized carbon filter for odour control.
-
Indoor Growing Applications – Ideal for hydroponics, greenhouse ventilation and grow tent extraction.
Product Specifications
Brand: RAM – Rapid Air Movement
Product: Mixed-Flow Inline Fan
Motor Type: AC
Fan Design: Mixed-Flow Inline Extractor
Available Sizes: 100mm, 125mm, 150mm and 200mm
Maximum Airflow: 199–840m³/h depending on model
Speed Settings: Two-Speed Manual Switching
Protection Rating: IP44
Impeller Material: ABS
Operating Temperature: -20°C to +50°C
Connection: IEC
Mounting: Integrated Mounting Bracket
Maintenance: Fast Clean Release System
Applications: Hydroponics, Grow Rooms, Grow Tents, Greenhouses and General Ventilation
Why Choose the RAM Mixed-Flow Inline Fan?
Maintaining reliable extraction and consistent airflow is essential for controlling heat, humidity and air quality in indoor growing environments.
The RAM Mixed-Flow Inline Fan delivers dependable performance through its powerful mixed-flow design, straightforward dual-speed control and convenient maintenance features.
From the compact 100mm fan delivering up to 199m³/h to the powerful 200mm model delivering up to 840m³/h, the RAM range offers practical extraction options for various growing spaces.
Whether you're upgrading an existing grow tent ventilation system or installing a new hydroponic extraction setup, this fan provides excellent airflow, reliability and value for money.
Choose the RAM Mixed-Flow Inline Fan for powerful extraction, quiet ventilation and dependable grow room airflow management.
Please note: This is the standard AC dual-speed version, not the RAM EC Mixed-Flow Fan. Carbon filters and ducting are sold separately. Confirm whether an IEC mains lead is included with your selected stock before advertising it as supplied.
